Pallet Flow Rack in Myrtle Beach, SC
Pallet flow uses inclined roller lanes with loading at one end and unloading at the other. That arrangement supports first-in, first-out movement for grocery, foodservice and temperature-controlled stock when the pallets and lane equipment are matched correctly.
Conway’s newer Ascott Valley space, Longs at Palmetto Coast Industrial Park and distribution operations along Florence’s I-95 corridor offer different ways to separate receiving from dispatch. The lane plan needs to follow the product’s movement through the building.
Rotation Begins with Lane Assignments
Group inventory by stock item and the rotation required. A lane of mixed expiration dates still needs a loading discipline; gravity alone does not manage the inventory records. Compare the pallet quantity per item with proposed lane depth, including what happens when a lane is nearly empty.
Grand Strand grocery and foodservice distributors build inventory ahead of the spring and summer visitor season. Pallet flow can hold repeat loads while maintaining two working faces, but loading aisles, picking aisles and staging consume space too. Compare the full layout rather than only the storage block.
Test the Pallet on the Rollers
Pallet underside construction, board placement, loaded weight and load stability determine how the pallet travels. Lane slope, speed-control devices and pallet separation need to be specified for the intended loads. Check representative pallets before committing to the lane arrangement.
Cooler and freezer applications require discussion of operating temperature, moisture and finish selection. Coastal humidity makes that conversation especially important in open-dock areas. Powder coat and galvanized options should be evaluated for the actual environment rather than selected solely by appearance.
Height and Working Faces in Local Buildings
Ascott Valley and Palmetto Coast include newer taller construction; Florence combines modern 32–32.5 ft clear space with older 14–24 ft stock. Check the lift truck’s reach and capacity at both lane faces. Receiving and dispatch cannot share the same narrow work area simply because the storage block fits.
Installation should include a planned lane check and a clear transition into loading. Preserve an area for representative pallets and operators to review travel before the inventory fills the lanes.
Compare layouts in Conway, Longs, Florence. Moving operations? Review our warehouse relocation service alongside the rack system options.
Pallet Flow Rack Questions
What type of pallet rack do I need?
Selective (teardrop) rack is the default when mixed items each need direct access. Pushback stores two to six pallets deep by item on a last-in, first-out basis; pallet flow suits dated stock needing first-in, first-out rotation; drive-in fits bulk storage of few items; cantilever carries long loads; carton flow serves case picking.
How much weight can pallet rack hold?
There is no single number. Beam capacity is stated per pair, per level, and frame capacity depends on frame height and beam spacing. We size beams and frames from your heaviest pallet, and the rated capacities go on load plaques at the installation.
Do you install the rack?
Yes. We handle design, supply and installation, with the work performed by experienced installation crews we schedule and manage.
Plan Your Myrtle Beach Rack Layout
Bring your pallet sizes, loaded weights, clear height and forklift details to a warehouse consultation.
